Eltex Tension Monitor

Sewing machine model, RS422 interfaced.

The Eltex Tension Monitor (ETM) is an on-line device for sewing machines and similar applications. The device monitors the thread tension and acts as a thread break detector. It enables the operator to keep the thread tension within the desired tension range for best operation and quality of the seam.

The ETM422 communicates through an RS422 interface to a host computer. This allows the user to set limits and to watch alarms and readings on the computer display.

Documents:

Leaflet

Manual

Technical Features:

Measuring range adjusted within: 0–1200cN
Available measuring ranges:
0–128cN, 0–256cN, 0–384cN, 0–512cN, 0–640cN, 0–768cN, 0–896cN,
0–1024cN, 0–1152cN, 0–1280cN, (0–1408cN, 0–1536cN)
Stop filter: 1–15 stitches
RS422 parameters: 9600 baud, 1 start bit, 8 data bits, 1 stop bit, 1 parity bit, even parity
Supply voltage 10–38 V DC
Maximum current consumption 50 mA
Maximum start peak current 500 mA (*Note 1)
Speed range 120–10 000 RPM
Message alert pulse length Minimum 2 seconds
Cable length between sensor head end electronics box 100 mm (50–500 mm on request)
Electronic box dimensions 100 x 61 x 25 mm (width x height x depth)
Sensor head dimensions 25 x 42 x 29 mm (width x height x depth)
Message alert output Optocoupler TLP127, max. 100 mA
Synchronisation input Optocoupler TLP112, Rin 1.5 kΩ, Vin 5–35 Vdc
Working ambient temperature range 15–45°C (60–110°F)
Working ambient humidity range 0–95% RH (at 45°C) no condensation
*Note 1: At supply voltage 38 Vdc and power supply start-up time = 30 ms.

Features:

• Monitors thread tension according to limits set by the software through RS422 interface.
• Programmable measuring ranges.
• Programmable RS422 message with peak tension and monitor status for every stitch.
• Programmable stop filter function.
• Generates stop pulse when thread tension is outside the selected Stop Limits.
• Separate sensor head and electronics enables fitting in tight areas.
• LED indication of monitored limits and synchronization input.
• Alarm message possible through RS422 line and separate optocoupler output.
• Factory calibrated – no manual reset.
• ESD protected inputs and outputs (optocoupler).

Typical Application

Advantages:

• Improves sewing quality.
• Allows you to operate with the correct thread tension.
• Acts as a thread stop motion / thread break detector.
• Protects against overtension.
• Alerts the operator to dirt and dust in the thread tensioners.
• Makes it easier for the operator to set the correct bobbin tension.

Eltex Tension Monitor

Sewing Machine Model, RS422 interfaced with miniature head.

The Eltex Tension Monitor (ETM) is an on-line device for sewing machines and similar applications. The device monitors the thread tension and acts as a thread break detector. It enables the operator to keep the thread tension within the desired tension range for best operation and quality of the seam.

The ETM422 communicates through an RS422 interface to a host computer. This allows the user to set limits and to watch alarms and readings on the computer display.

This model has a low profile miniature sensor head which allows for a better placement on the machine.

Documents:

Leaflet

Technical Features:

Measuring range adjusted within: 0–1200cN
Available measuring ranges:
0–128cN, 0–256cN, 0–384cN, 0–512cN, 0–640cN, 0–768cN, 0–896cN,
0–1024cN, 0–1152cN, 0–1280cN, (0–1408cN, 0–1536cN)
Stop filter: 1–15 stitches
RS422 parameters: 9600 baud, 1 start bit, 8 data bits, 1 stop bit, 1 parity bit, even parity
Supply voltage 10–38 V DC
Maximum current consumption 50 mA
Maximum start peak current 500 mA (*Note 1)
Speed range 120–10 000 RPM
Message alert pulse length Minimum 2 seconds
Cable length between sensor head end electronics box 100 mm (50–500 mm on request)
Electronic box dimensions Part No 14630 0,5 m, Part No 14631 0,1 m
Sensor head dimensions see drawing
Message alert output Optocoupler TLP127, max. 100 mA
Synchronisation input Optocoupler TLP112, Rin 1.5 kΩ, Vin 5–35 Vdc
Working ambient temperature range 15–45°C (60–110°F)
Working ambient humidity range 0–95% RH (at 45°C) no condensation
*Note 1: At supply voltage 38 Vdc and power supply start-up time = 30 ms.

Features:

• Monitors thread tension according to limits set by the software through RS422 interface.
• Programmable measuring ranges.
• Programmable RS422 message with peak tension and monitor status for every stitch.
• Programmable stop filter function.
• Generates stop pulse when thread tension is outside the selected Stop Limits.
• Separate sensor head and electronics enables fitting in tight areas.
• LED indication of monitored limits and synchronization input.
• Alarm message possible through RS422 line and separate optocoupler output.
• Factory calibrated – no manual reset.
• ESD protected inputs and outputs (optocoupler).

Advantages:

• Improves sewing quality.
• Allows you to operate with the correct thread tension.
• Acts as a thread stop motion / thread break detector.
• Protects against overtension.
• Alerts the operator to dirt and dust in the thread tensioners.
• Makes it easier for the operator to set the correct bobbin tension.

Typical Application

Sensor head dimensions:

Eltex Tension Monitor

Sewing machine ETM model 14600.

The Eltex Tension Monitor (ETM) is an on-line device for sewing machines
and similar applications. The device monitors the thread tension and acts as a
thread break detector. It enables the operator to keep the thread tension within the
desired tension range for best operation and quality of the seam.

The ETM indicates, with LED’s, if the thread tension is outside the selected Indication
Limits. If the thread tension goes outside the selected Stop Limits, the ETM will
generate a stop signal to the machine.

Documents:

Leaflet

Manual

Technical Features:

Supply voltage: 9–14 V DC
Maximum current consumption: 50 mA (typical value 32 mA)
Maximum current, stop output: 300 mA (NPN open collector)
Maximum voltage at stop output (relay coil): 30 V DC
Speed range: 80–10 000 RPM
Maximum voltage at Synchronization input: 30 V DC. Vinlow: 0–1.2 V
Vinhigh: 6.0–30 V
Working ambient temperature range: 15–45°C (60–110°F)
Stop pulse length: 2 seconds
Cable length between sensor head end electronics box: 100 mm (50–500 mm on request)
Electronic box dimensions (width x height x depth): 115 x 61 x 25 mm
Sensor head dimensions (width x height x depth): 25 x 42 x 29 mm

Features:

• Monitors thread tension according to selected Indication Limits.
• Generates stop pulse when thread tension is outside the selected Stop Limits.
• Separate sensor head and electronics enables fitting in tight areas.
• Easy setting and clear readings through standard code switches.
• LED indication at Synchronization input.
• Open collector stop output allows different power sources for stop relay.
• Factory calibrated – no manual reset.
• ESD protected inputs and outputs.
• Standard 9-pole D-sub connector.

Typical Application

Advantages:

• Improves sewing quality.
• Allows you to operate with the correct yarn tension.
• Acts as a thread stop motion / thread break detector.
• Protects against overtension.
• Alerts the operator to dirt and dust in the thread tensioners.
• Makes it easier for the operator to set the correct bobbin tension.
• Gives you a possibility to equalize the bobbin thread consumption (multineedle machines).

Models:

14600 – Calibrated for 0–1000 cN
14604 – Calibrated for 0–400 cN
14606 – Calibrated for 0–600 cN
Other tension ranges on request
